Product name: Onboard Audio System
Figure1: LT-AS04 Onboard Audio Server_front
Figure 2: LT-AS04 Onboard audio server_back
Figure 3:LT-AR04 Onboard audio receiver
Figure 4: BP-H2-5 Power HUB
Product name: Onboard Audio System
Figure1: LT-AS04 Onboard Audio Server_front
Figure 2: LT-AS04 Onboard audio server_back
Figure 3:LT-AR04 Onboard audio receiver
Figure 4: BP-H2-5 Power HUB
Ltime's wireless multi-channel on-board audio system is applied to various passenger and tourist bus, passenger trains and cruise ships. The system adopts the latest FM technology and consists of an 8-channel audio server (LT-AS04), multiple audio receivers (LT-AR04) and Power supply hubs (BP-H2-5).
The audio receiver is usually installed in the front or rear of the seat for passengers to use. The preferred audio program is selected through multiple playback channels of the audio receiver. At the same time, the audio receiver also has the function of charging the mobile terminal device through its USB interface. The audio server supports TF card or U disk to store audio resources, and connects with each audio receiver wirelessly (FM), which is easy to update and maintain. The system supports emergency broadcast function. When the driver starts an emergency broadcast, all audio receivers will go to silent mode automatically, so that the passengers can get the information from the vehicle speakers in time.
A large number of high-precision electronic components are widely used in the design and manufacture, which have passed EMC test. The frame is made of PC material which has passed anti-flame and odor test. All products have obtained E-MARK certification to ensure the quality and performance.
Ltime's wireless multi-channel on-board audio system is applied to various passenger and tourist bus, passenger trains and cruise ships. The system adopts the latest FM technology and consists of an 8-channel audio server (LT-AS04), multiple audio receivers (LT-AR04) and Power supply hubs (BP-H2-5).
The audio receiver is usually installed in the front or rear of the seat for passengers to use. The preferred audio program is selected through multiple playback channels of the audio receiver. At the same time, the audio receiver also has the function of charging the mobile terminal device through its USB interface. The audio server supports TF card or U disk to store audio resources, and connects with each audio receiver wirelessly (FM), which is easy to update and maintain. The system supports emergency broadcast function. When the driver starts an emergency broadcast, all audio receivers will go to silent mode automatically, so that the passengers can get the information from the vehicle speakers in time.
A large number of high-precision electronic components are widely used in the design and manufacture, which have passed EMC test. The frame is made of PC material which has passed anti-flame and odor test. All products have obtained E-MARK certification to ensure the quality and performance.
*The latest FM technology
*Wireless transmission
*Multichannel audio playback
*TF card or U disk storage, easy to update
*USB charging interface
*Support emergency broadcast
*Anti-flame material
*E-MARK certification
*Better travel experience
*The latest FM technology
*Wireless transmission
*Multichannel audio playback
*TF card or U disk storage, easy to update
*USB charging interface
*Support emergency broadcast
*Anti-flame material
*E-MARK certification
*Better travel experience
1 AUDIO SERVER, MODEL: LT-AS04
BASIC PARAMETERS | |
Operating Voltage | DC 12/24V |
Working Current | 500mA@24V |
Max Power(USB Charging Included) | 1.2W |
Operating Temperature | -20℃~+70℃ |
Product Size | 34.5*14.2*5.2cm |
Net Weight | 1.5kg |
2 AUDIO RECEIVER, MOFEL: LT-AR04
BASIC PARAMETERS | |
Operating Voltage | DC 5V |
Working Current | 2.5A@5V |
Max Power(USB Charging Included) | 7.5W |
Operating Temperature | -20℃~+70℃ |
Product Size | 90*50*25mm |
Net Weight | 100g |
3 HUB (Power distribution unit), MODEL: BP-H2-5
BASIC PARAMETERS | |
Input Voltage | DC 9~32V |
Output Voltage | DC 5V |
Operating Temperature | -20℃~+80℃ |
Product Size | 90*66.5*30mm |
Net Weight | 100g |
1 AUDIO SERVER, MODEL: LT-AS04
BASIC PARAMETERS | |
Operating Voltage | DC 12/24V |
Working Current | 500mA@24V |
Max Power(USB Charging Included) | 1.2W |
Operating Temperature | -20℃~+70℃ |
Product Size | 34.5*14.2*5.2cm |
Net Weight | 1.5kg |
2 AUDIO RECEIVER, MOFEL: LT-AR04
BASIC PARAMETERS | |
Operating Voltage | DC 5V |
Working Current | 2.5A@5V |
Max Power(USB Charging Included) | 7.5W |
Operating Temperature | -20℃~+70℃ |
Product Size | 90*50*25mm |
Net Weight | 100g |
3 HUB (Power distribution unit), MODEL: BP-H2-5
BASIC PARAMETERS | |
Input Voltage | DC 9~32V |
Output Voltage | DC 5V |
Operating Temperature | -20℃~+80℃ |
Product Size | 90*66.5*30mm |
Net Weight | 100g |
